Defining the e8350 Satellite Router Rear Panel
A description of each connector and indicator is shown in Table 9.
The RJ-45 Console port pin assignments are listed in Table 10.
Table 9. e8350 Satellite Router Connectors
Label Connector Type Interface and Purpose
10 MHz 75 ohm, BNC External 10 MHz clock
TX Out 75 ohm, F-Type L-band transmit signal to Block Up Converter
(BUC) capable of 10 MHz reference and +24
VDC, 3.5A (or +48 VDC, 3A) maximum power
supply to BUC
RS-232 HD-15 Female Serial interface connection used for antenna
pointing
RX Out 75 ohm, F-Type with
DC Blocked
Termination
Monitoring of the receive signal from LNB
output, -10 dB nominal composite, buffered
RX In 75 ohm, F-Type L-band receive signal, capable of 10 MHz
reference and DC power to LNB
USB USB Universal Serial Bus interface connection
CONSOLE RJ-45 RS-232 servicing serial connection console to
PC or laptop
LAN A RJ-45 Category-5 STP or UTP cable, 10/100
Base-T Ethernet LAN port connects the e8350
and e800 iCONNEX Satellite Router models to
the customer LAN hub/switch
LAN B RJ-45 Category-5 STP or UTP cable, 10/100
Base-T Ethernet LAN port connects the e8350
and e800 iCONNEX Satellite Router models to
the customer LAN hub/switch
100-240 V~
4A/2A
50/60 Hz
IEC-320-C14 AC input
Table 10. RJ-45 Pin Assignments
PIN SIGNAL NAME DESCRIPTION
1 Not Connected Do not connect
2 Reserved (Tx) Do not connect
3 Transmit Data (TxD) RS-232 voltage level compliant transmit data
signal for debug use only
4 Ground (GND) Ground
5 Ground (GND) Ground
