12 iDirect Evolution 8000 Series Satellite Router Installation and Safety Manual
iCONNEX e800 Satellite Router Specifications
3.2 iCONNEX e800 Satellite Router Specifications
This section contains mechanical and environmental specifications, power specifications, and
RF specifications for the iCONNEX e800 Satellite Router.
3.2.1 Mechanical and Environmental Specifications
Ensure that the installation site can accommodate the mechanical and environmental
specifications for the iCONNEX e800 Satellite Router as defined in Table 5.
Transmit Carrier Suppression ≥ 30 dBc
Discrete Spurs, Harmonics and
Nonharmonics
≥ 50 dBc, with output ≥ -15 dBm
Modulator Spectral Shaping Intelsat: IESS-309, MIL-STD-188-165A Section 5.1.6.4.1 Spectral
Confinement
Transmitter On/Off Ratio ≥ 50 dBc, with output power ≥ -15 dBm
Table 4. e8350 Satellite Router RF Specifications (continued)
Category Description
Table 5. e800 iCONNEX Satellite Router Mechanical and Environmental
Specifications
Category Description
Weight 1.4 lbs (0.63 Kg)
Heat Dissipation 35W (120 BTU/hour)
Ambient Temperature
Operational:
Storage:
14°F to 131°F (-10°C to 55°C) at 10,000 feet
-30°F to 176° F (-34°C to 80°C)
Temperature Gradient Shall never exceed 1.0°C/min
Relative Humidity
Operational:
Storage:
0 to 90% noncondensing
5 to 93% noncondensing
Altitude
Operating:
Storage:
≤ 10,000 feet (3048m)
≤ 30,000 feet (9144m)
