Power Connectors
Port specifications for the iCONNEX e800 Satellite Router are listed in Table 18.
5.2 Power Connectors
This section describes the details of the iCONNEX e800 Satellite Router power connectors. The
connectors include:
• iCONNEX e800 Satellite Router Remote ON/OFF Switch Connector
• iCONNEX e800 Satellite Router Remote LED Connector
• iCONNEX e800 Satellite Router DC Power Connector
Table 18. e800 iCONNEX Satellite Router Port Specifications
Port Designator Port Name DESCRIPTION
J18 Power
Connector
MOLEX P/N 501844-1410 (mates with MOLEX P/N
51353-1400)
J2 10 MHz BNC external 10 MHz connector (future use)
J3 TX Out • F-Connector, female, 3/8”, 32 thread
• 75 ohm nominal
• BUC Voltage: +24V or +48V (depending on input
voltage)
Note: The BUC voltage on the Tx connector is
approximately equal to the input voltage. For
example, if the input voltage is +48V,
approximately +48V is present at the TX
connector.
J5 RX Out • F-Connector, female, 3/8”, 32 thread
• 75 ohm nominal
• DC blocked port with terminator
J6 Rx in • F-Connector, female, 3/8”, 32 thread
• 75 ohm nominal
• LNB Voltage: +18.8 VDC nominal at 500 mA maximum
J7 USB Future use
J8 (left) Console RJ-45, serial, RS-232
J8 (right) Lan A RJ-45, 10/100 Base-T
J13 Lan B RJ-45, 10/100 Base-T
J4 RS232/GPIO HD-15, General Purpose Input/Output, serial
JP1 Remote
ON/OFF
Switch
MOLEX P/N 89400-0320 (mates with MOLEX part
number 87369-0300)
JP2 Remote LED
Display
MOLEX P/N 87831-2020 (mates with MOLEX part
number 87568-2063)
