50 iDirect Evolution 8000 Series Satellite Router Installation and Safety Manual
LED Status and Definitions
5.5 LED Status and Definitions
The iCONNEX e800 Satellite Router has ten LEDs to indicate status. There are three LEDs on
the rear edge (the edge with the RJ-45 and F-connectors) and seven LEDs on the front edge
(the edge with LEDs only). Refer to Figure 20 on page 44 for both front and rear edge LED
designations.
5.5.1 Front Edge Status LEDs
There are seven front panel LEDs to indicate the status of the iCONNEX e800 Satellite Router.
A description of each front panel LED is listed in Table 23.
Table 23. Front Panel LEDs
LED INDICATOR COLOR DESCRIPTION
DS2 POWER Off
Solid Green
DC power is absent or there is an on-board power
regulator problem.
The internal power regulator is powered on; boot
loader has started.
DS3 STATUS Flashing Green
Solid Green
Red
Indicates initial bootup sequence; DRAM test is in
progress.
The DRAM test passes and operation is normal.
Indicates a serious fault or failure within the software,
hardware, or configuration. May indicate that the
DRAM test has failed.
DS4 NET Flashing Yellow
Solid Yellow
Flashing Green
Solid Green
Indicates that the hub downstream carrier has not
been acquired.
Indicates that the hub downstream carrier has been
acquired.
Downstream carrier is acquired and the TDMA
upstream has been acquired by the hub.
Network has been acquired.
DS6 Tx Solid Yellow
Solid Green
Transmitter is disabled.
Transmitter is enabled.
DS7 Rx Solid Yellow
Solid Green
Receiver is not locked to the downstream carrier.
Receiver is locked to the downstream carrier.
DS8 CRYPTO Off
Solid Green
FIPS is not enabled.
FIPS is enabled.
DS10 TEMP Off
Solid Yellow
Red
Indicates normal operating temperature.
Operating temperature is nearing the over
temperature threshold.
Operating temperature threshold has been exceeded.
