iDirect Evolution 8000 Series Satellite Router Installation and Safety Manual 39
Maintaining the Remote
There are five LEDs on the rear of the e8350 Satellite Router that indicate whether certain
components are powered on or off. These LEDs are described in Table 17.
4.8 Maintaining the Remote
The e8350 Satellite Router requires basic maintenance to keep it running efficiently and to
prolong its life. However, the only maintenance you need to perform, without explicit
directions from iDirect, is to maintain the temperature and keep the external areas free from
dust or dirt.
Note: There are no user-serviceable parts within the e8350 Satellite Router. Do not
attempt to repair/replace a malfunctioning or defective component/module.
Doing so may void the warranty.
Table 17. Rear Panel LED Indicators
LED Label LED Color Status
INPUT PWR
Off Indicates that power is absent.
Green Indicates that power is present.
BUC PWR
Off Indicates that the BUC power is not being
supplied.
Green Indicates that the BUC power
(+24 VDC or +48 VDC) is being supplied.
Red Indicates a BUC problem or an IFL
disturbance.
LNB PWR
Off Indicates that the LNB power is not being
supplied.
Green Indicates that the LNB power (+19 VDC
nominal) is being supplied.
Red Indicates an LNB problem or an IFL
disturbance.
AC Green AC input is nominal.
Off AC input not detected.
DC Green DC output is nominal.
Off DC output not detected.
