iDirect Evolution 8000 Series Satellite Router Installation and Safety Manual 47
Power Connectors
5.2.3 iCONNEX e800 Satellite Router DC Power Connector
The iCONNEX e800 Satellite Router JP18 power connector and pin assignments are shown in
Figure 23 and Table 21:
Figure 23. JP18 Pin Numbering
8 RMT TX LED GRN
9 RMT RX LED YEL
10 RMT RX LED GRN
11 RMT ENCRYPT LED YEL
12 REMT ENCRYPT LED GRN
13 RESERVED (Do not use)
14 RESERVED (Do not use)
15 RMT OVERTEMP STAT LED RED
16 RMT OVERTEMP LED YEL
17 N/C
18 N/C
19 GROUND
20 +3.3V
Table 21. JP18 Pin Assignments
Pin
Signal Name
1INPUT PWR
2INPUT PWR
3INPUT PWR
4INPUT PWR
5INPUT PWR
Table 20. JP2 Connector Pin Assignments (continued)
Pin Signal Name
