24 iDirect Evolution 8000 Series Satellite Router Installation and Safety Manual
Defining the e8350 Satellite Router Rear Panel
A diagram of the pin numbering scheme for the Console, LAN A, and LAN B RJ-45 ports is
shown in Figure 7. In this diagram, two RJ-45 ports are shown together (see Console and LAN
A in Figure 6 on page 22.
Figure 7. Console Port Pin Numbering
6 Receive Data (RxD) RS-232 voltage level compliant receive data
signal for debug use only
7 Reserved (Rx) Do not connect
8 Not Connected Do not connect
Table 10. RJ-45 Pin Assignments (continued)
PIN SIGNAL NAME DESCRIPTION
