iDirect Evolution X1 Outdoor Satellite Router Installation and Safety Manual 1
1 Introduction
The iDirect Evolution X1 Outdoor Satellite Router is a cost-effective remote bundle ideal for
large, narrowband networks for SCADA, Point of Sale and ATM applications. The X1 Outdoor
Satellite Router features DVB-S2/ACM and TDMA, basic routing, VLAN functionality and
Quality of Service (QoS), and is embedded in a IP67 weatherproof enclosure enabling an
extended temperature range, and passive cooling. The bundle can run on battery power that
can be recharged by solar sources.
This manual explains how to safely install and maintain the X1 Outdoor Satellite Router, and it
includes important safety information.
The iDirect Evolution X1 Outdoor Satellite Router is shown in Figure 1.
Figure 1. X1 Outdoor Satellite Router, Left, and the Power Module, Right
The connectors are described in Chapter4, Physical Interfaces.
