iDirect Evolution X1 Outdoor Satellite Router Installation and Safety Manual 11
Power Specifications
3.2 Power Specifications
The X1 Outdoor Satellite Router power specifications are defined in Table 4.
Note: AC power is supplied to the external Power Module. The Power Module supplies
DC power only to the X1 Outdoor Satellite Router. See Figure 2 on page 14 and
Figure 4 on page 16 which show the finished units and all connectors.
Table 4. Power Specifications
Category Description
Input Voltage Range 100 - 240 V (VAC) Single Phase to 24 VDC (2.7 Amp) as output to the
X1 Outdoor Satellite Router
Frequency 50 - 60 Hz
AC Power Consumption  1.2 Amp typical at 115V AC (full load)
DC Power Connector BUC Power (IFL) +24 VDC, 25W max (up to 50C) for up to a 3W BUC
LNB Power (IFL) +24 VDC 170mA (DiSEqC) 22 kHz DiSEqC tone
NOTE: Use only the iDirect approved Power Module.
Protection • Internal, primary current fuse, inside power supply
• Over current protection
• Short circuit protection
Power Factor Correction Complies with EN61000-3-2 Class B and EN61000-3-3
Efficiency 86% minimum
Input Transient Response 4% (recovery within 1% less than 500msec for 50-75% and 75-50%
load step)
AC Input Connector IP67 AC Connector
AC Power Cord 18 AWG, country dependent, see Table 11 on page 20
