RF Specifications
3.3 RF Specifications
The iDirect Evolution X1 Outdoor Satellite Router RF specifications are described in Table 5.
Table 5. RF Specifications
Category Description
Bundled ODU/Antenna BUC: Ku-Band 1.5 W or 3W universal (13.75 - 14.5 GHz)
LNB: Ku-Band universal PLL (multiple sub-bands)
Antenna: Ku-Band 75cm or larger
Frequency Range
Transmit:
Receive:
950-1700 MHz, Composite Power 0dBm/-30dBm
950-2150 MHz, Composite Power -5dBm/-65dBm
Frequency Tuning Step Size
Transmit:
Receive:
0.6 Hz
Sub-Hertz with Demodulator
RF Power Range
Transmit:
Receive:
-30 dBm to 0 dBm
Single Carrier Input Power:
Minimum: -130 +10Log
10
(Symbol Rate) dBm to - 5 dBm
Pmax = 0 dBm minimum, 30 dB attenuation adjustable in 1 dB
steps
Composite Wideband Input Power: -5 dBm (maximum)
RF Power Adjustability
Transmit:
Receive:
1.0 dB Nominal Step Size
Under AGC for all valid Rx input power range
Typical Transmit and Receive
Phase Noise (dBc/Hz) at:
Typical Phase Jitter at
14 KHz to 1 MHz:
 1.8 rms
Transmit Carrier Suppression  40 dBc (max)
Discrete Spurs, harmonics and
non-harmonics
 50 dBc, with output  -15 dBm Inband 32 dBc
Modulator Spectral Shaping DVB-S2 (ETSI EN302307)
Transmitter On/Off  50 dBc, with output power  -15 dBm
Frequency Phase Noise
1 KHz -75
10 KHz -85
100 KHz -95
1 MHz -105
