32 iDirect Evolution X1 Outdoor Satellite Router Installation and Safety Manual
Preparing and Connecting the Coax RX and TX cables
5.9 Preparing and Connecting the Coax RX and TX
cables
This section explains how to install the coax RX and TX cables. For coax cable preparation
details see AppendixC, Preparing the Coax Cable.
Table 13 describes connecting the RX and TX coax cables.
4. Final assembly.
Completed and connected LAN assembly shown.
Table 12. RJ 45 LAN Ethernet Cable Installation Steps (continued)
Step Instructions Diagram
CAUTION
After tightening the power connectors, wrap
with weatherproofing (self-amalgamate)
tape, if necessary, following manufacturer’s
guidelines.
All cables should be installed with a drip
loop.
Table 13. Coax RX and TX Cable Installation
Step Instructions Diagram
1.
Insert F assemblies into RX-in interface and
lock the connector.
