iDirect Evolution X1 Outdoor Satellite Router Installation and Safety Manual 35
Connecting the Power Module
5.10.2 Connecting the AC Power to The Power Module
Table 15 on page 36 shows the detailed installation steps for the Power Module and gland
assembly and Figure 16 shows a blow up of the gland assembly parts.
Figure 16. AC Power Gland Assembly
CAUTION
Install power on a GFI (Ground Fault
Interrupter) protected circuit.
All cables should be installed with a drip
loop.
