prox.pad Installation/Programming Manual
Action Desired Press Details
Change Platform Parameters 32 # parameter # value # ** See Chart Below
Parameter Value
2 – 26 Bit Facility Code (for commands 51 &
56)
0 – 255; (Default = 1)
Note: IEI Cards are Facility Code 11
3 – Process Card Timer 2 – 240; ¼ sec. Increments
(Defaults to 4 = 1 sec.)
4 – Invalid PIN Lockout Attempts 1 – 50 (Default = 5)
5 – Invalid PIN Lockout Duration 1 – 255; 5 sec. increments;
(Defaults to 60 = 5 Minutes)
Set System Time 41 # hhmm # 0 # **
hhmm=hour/minute (24 Hour
Format)
Set System Date 42 # mmddyy # dow # **
mmddyy=month, date, year;
dow=day of week, 1=Sunday
Set Door Number 43 # nnnn # 0 # ** nnnn=door number (4 digits)
Set Propped Door Time 44 # ttt # 0 # **
ttt=propped door time, to nearest
10’s seconds, entered as 30-990;
(default=30 secs)
(this sets the time for both Aux
Relay and local sounder)
Set Forced Door Time 45 # ttt # 0 # **
ttt=forced door time, to nearest 10’s
seconds, entered as 30-990;
(default=10 secs)
(this sets time for both Aux Relay
and local sounder)
Reset System Defaults Only 40 # 00000 # 00000 # **
Does not delete users
See section 2.7.6a
Delete Entire Memory and Reset
System Defaults
46 # 00000 # 00000 # **
Deletes all memory including users
See section 2.7.6b
Program User – Code Only 50 # user type # user location #
code *repeat code *
User Types:
0-Toggle/latch lock
1-Normal access
2-log Dump
3-Lockout
Program User – Code AND Card
By Presenting Card
50 # user type # user location #
code * repeat code * <present
card>
User Types:
0-Toggle/latch lock
1-Normal access
2-log Dump
3-Lockout
Document # 6055676, Rev 2.2, D4b Page 57 of 86
