ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
Data (byte 0) or
diagnostic data
User data (byte 0) or error codes
8 bits
User data: 0x00...0xFF
Error codes: → Failure codes (→ p. 80)
Data (byte n)
User data (byte n)
8 bits
0x00...0xFF
>
Failure codes
15475
Error code
Description
0x71
Service not available (unknown command has been sent to the IO-Link port)
0x72
Port blocked (another cyclic process accesses the IO-Link port)
0x74
Invalid data (wrong parameter has been sent in the command)
0x76
Wrong port (wrong port number)
0x77
Wrong port function (wrong port function or wrong parameter has been sent to the device)
0x78
Invalid length (set length is > 0x20)
0x80
Error in the device application
