ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
Command 0x30 – set fail-safe data pattern
23464
The command sets the behaviour of the outputs when the EtherNet/IP connection and the
corresponding fail-safe values are interrupted.
Corresponding parameter: [Fail-safe Mode] (→ Port configuration (→ p. 70))
The number of the required fail-safe values results from the size of the output data (→ Process
data length (→ p. 69)).
>
Command request
23527
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
4
Port no. (LSB)
5
Port no. (MSB)
6
reserved
7
reserved
8
reserved
9
reserved
10
Trigger
0x30
11
Fail-safe mode
12
Byte Length N
13
Fail-safe data (byte 0)
...
...
44
Fail-safe data (byte 31)
45
reserved
Legend:
Port no. (LSB)
Number of the IO-Link port (low byte)
Port no. = 0xXXYY
 Port no. (LSB) = 0xYY
8 bits
0x01 = port X01
0x02 = port X02
...
0x08 = port X08
Port no. (MSB)
Number of the IO-Link port (high byte)
Port no. = 0xXXYY
 Port no. (MSB) = 0xXX
8 bits
0x00
Fail-safe mode
Behaviour of the outputs when the
EtherNet/IP connection is interrupted
and setting of the corresponding
fail-safe values
8 bits
0x00 = No Fail-safe
0x01 = Fail-safe Reset Value
0x02 = Fail-safe Old Value
0x03 = Fail-safe with Pattern
Trigger
Control command execution
1 bit
0x0 = do not process command
0x1 = execute command
Byte Length N
Number of the bytes that contain
fail-safe values
8 bits
0x00 = 0 bytes
...
0x20 = 32 bytes
Fail-safe data
(byte n)
Fail-Safe value n (n = 0...31)
8 bits
0x00...0xFF
