ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Programming Use functions of the ifm package
>
7.4.2 Configure system
17450
To configure the system of the device, use the following function blocks:
Name
Description
Reference
QuickSetupASi_Master
Execute quick setup routine on an AS-i master
→ QuickSetupASi_Master (→ p. 109)
Set_TimeDate
Set system time (date, time) of the system
→ Set_TimeDate (→ p. 111)
Get_FieldbusInfo
Read fieldbus type, the status of the field bus connection
and the parameters of the fieldbus interface
→ Get_FieldbusInfo (→ p. 107)
>
7.4.3 Configure AS-i master
17448
To configure the AS-i masters of the device, use the following function blocks:
Name
Description
Reference
Set_Mode
Set operating mode of the AS-i master (projecting mode
or protected operation)
→ Set_Mode (→ p. 93)
Set_ASi_Config
Set diagnostic functions of the AS-i master (double
address recognition, earth fault detection)
→ Set_ASi_Config (→ p. 89)
Set_AdressMode
Set automatic addressing of the AS-i master
→ Set_AddressMode (→ p. 87)
>
7.4.4 Configure AS-i slaves
17449
To configure the AS-i slaves, that are connected to the device, use the following function blocks:
Name
Description
Reference
Set_SlaveAddress
Change address of an AS-i slave
→ Set_SlaveAddress (→ p. 98)
Set_SlaveParameter
Change I/O configuration and ID codes (IO, ID, ID1, ID2)
of an AS-i slave
→ Set_SlaveParameter (→ p. 102)
Set_SlaveExtendedID1
Extended ID1 of an AS-i slave
→ Set_SlaveExtendedID1 (→ p. 100)
