Preliminary note Symbols and styles used
1.3 Symbols and styles used
13839
► ...
Instructions
> ...
Reaction, result
→ ...
Cross-reference or internet link
123
0x123
0b010
Decimal number
Hexadecimal number
Binary number
[...]
Designation of pushbuttons, buttons or indications
>
1.4 Overview: User documentation for AS-i Gateway AC14
6998
ifm electronic provides the following user documentation for the models of the device class "AS-i
Gateway AC14":
Document
Content / Description
Data sheet
Technical data of the device as a table
Operating instructions *
 Notes on mounting and electrical installation of the device
 Set-up, description of the operating and display elements, maintenance information, scale
drawing
Device manual
 Notes on operation of the device via GUI and web interface
 Error elimination
 Description of the fieldbus data
Supplement device manual
 Description of the acyclic data sets and the command interface
Programming manual
 Creation of a project with the device using CODESYS
 Configuration of the device using CODESYS
 Programming of the PLC of the device
 Description of the device-specific CODESYS function libraries
*... The operating instructions are supplied with the device.
The user can download all documents from the ifm website.
