ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Appendix Library ACnnnn_Utils.library
>
Set_AddressMode
16018
Function block type:
Function block (FB)
Library:
ACnnnn_Utils.library
Symbol in CODESYS:
>
Description
16146
The FB activates/deactivates the parameter "Automatic addressing" for the selected AS-i master.
>
Input parameters
16147
Parameter
Data type
Description
Possible values
xExecute
BOOL
Control execution of the FB
FALSE
Stop FB execution
TRUE
Start one-time FB
execution
enASi_Master
ASI_MASTER
Select AS-i master
Master_1
AS-i master 1
Master_2
AS-i master 2
enAuto_Address_Mode
ASI_ADDRESS_MODE
Parameter
activates/deactivates the
automatic addressing mode.
Auto_address_disable
Automatic
addressing inactive
Auto_address_enable
Automatic
addressing active
