IFM AC1421 - Set_Mode

93
ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Appendix Library ACnnnn_Utils.library
>
Set_Mode
16021
Function block type:
Function block (FB)
Library:
ACnnnn_Utils.library
Symbol in CODESYS:
>
Description
16155
The FB changes the operating mode (protected operation, projection mode) of the selected AS-i
master.
>
Input parameters
16156
Parameter
Data type
Description
Possible values
xExecute
BOOL
Control execution of the FB
FALSE
Stop FB execution
TRUE
Start one-time FB execution
enASi_Master
ASI_MASTER
Select AS-i master
Master_1
AS-i master 1
Master_2
AS-i master 2
enMode_ASi_Master
ASI_MASTER_
MODE
Operating mode of the AS-i master
Closed_
mode
protected mode active
Project_
mode
projection mode active
