ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Appendix Library ACnnnn_Utils.library
>
Set_ASi_Config
16019
Function block type:
Function block (FB)
Library:
ACnnnn_Utils.library
Symbol in CODESYS:
>
Description
16149
The FB activates/deactivates the parameters "double address recognition" and "earth fault detection"
for the selected AS-i master.
>
Input parameters
16150
Parameter
Data type
Description
Possible values
xExecute
BOOL
Control execution of the FB
FALSE
Stop FB execution
TRUE
Start one-time FB execution
enASi_Master
ASI_MASTER
Select AS-i master
Master_1
AS-i master 1
Master_2
AS-i master 2
xDoubleAdrDetection
BOOL
Activate/deactivate "Double address
recognition"
FALSE
Double address recognition
inactive
TRUE
Double address recognition
active
xEarthFaultDetection
BOOL
Activate/deactivate "Earth-fault
detection"
FALSE
Earth-fault detection inactive
TRUE
Earth-fault detection active
