ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Operation Display web visualisation
>
8.4 Display web visualisation
17063
To display the created web visualisation:
Requirements:
> PC/laptop is connected to the configuration interface (X3) of the device (→ device manual: Configuration
interface: connection concepts)
CODESYS PLC appliation
► Download PLC application with web visualisation to the device and start it (→ Download the application to the
device (→ p. 50)).
► On PC/laptop: Start web browser.
► Enter the following in the address line and press [ENTER] to confirm:
<IP address-of-the-device>:<8080>/myvisu.htm
myvisu is the user-defined name of the visualisation (→ Change properties of the web visualisation
(→ p. 43)).
> Web browser shows the web visualisation of the device.
ifm system solution
► Install the ifm system solution on the device and start it (→ device manual, Install single/basic app or Install
multi app).
► Display informationen about the installed ifm app (→ device manual, Show information about installed ifm
apps).
► Call hyperlink of the ifm app.
> Web browser shows the web visualisation of the ifm system solution.
