ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Appendix Library ACnnnn_Utils.library
>
Get_CDI
16006
Function block type:
Function block (FB)
Library:
ACnnnn_Utils.library
Symbol in CODESYS:
>
Description
16045
The FB reads the configuration data (Configuration Data Image = CDI) of the slaves at the selected
AS-i master and provides the values in an array. The configuration data of a slave consists of the
registers IO, ID, ID1 and ID2.
>
Input parameters
16046
Parameter
Data type
Description
Possible values
xExecute
BOOL
Control execution of the FB
FALSE
Stop FB execution
TRUE
Start one-time FB execution
enASi_Master
ASI_MASTER
Select AS-i master
Master_1
AS-i master 1
Master_2
AS-i master 2
