Programming Use visualisations
>
7.5.3 Create a visualisation
17061
Create a seperate visualisation object for each target and web visualisation.
To create a visualisation for a PLC application:
► In the device tree: double-click on [Visualization]
> The visualisation editor with a tool box appears:
► Create the visualisation using the tools.
► Save the project to apply changes.
