ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Operation Display target visualisation
>
8.5 Display target visualisation
20256
After compilation of the project and download to the device the user has to start the target
visualisation:
 CODESYS / higher-level Fieldbus controller:
► Execute system command [Display target visualisation] (→ Device manual, Command 0x0110 – Display target
visualisation)
 GUI / web interface:
► Activate target visualisation via the menu (→ Device manual: Show target visualisation)
OR:
Switch between target visualisation and menu with the key combination [] + [].
If the device does not react to the pressing of [] + [], the key combination is deactivated.
► Activate the key combination with the system command [Display target visualisation].
After a restart of the device the menu view of the GUI appears by default.
► With the FB ACnnnn_SysCmd (→ p. 121)execute the system command [Display target
visualisation] at the start of the PLC application.
Further information: → Device manual: Command 0x0110 – Display target visualisation"
