ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Appendix Library ACnnnn_SYS_CMD.library
>
9.2 Library ACnnnn_SYS_CMD.library
ACnnnn_SysCmd .................................................................................................................................121
17723
>
9.2.1 ACnnnn_SysCmd
15890
Function block type:
Function block (FB)
Library:
ACnnnn_SYS_CMD.library
Symbol in CODESYS:
>
Description
15893
Using the FB, individual commands can be sent to the system or to an AS-i master.
Each command refers to the data structures of one of the following elements:
 Command request channel: → Example: Change language setting of the device (→ p. 126)
 Command response channel: → Example: Date / time / read NTP settings (→ p. 127)
 Acyclic data record (DSx): → Example: Read LCEMS, LCEAS and LDAE of AS-i master 2 (→ p. 128)
