Appendix Library ACnnnn_SYS_CMD.library
>
Input parameters
15895
Parameter
Data type
Description
Possible values
xExecute
BOOL
Control execution of the FB
FALSE
Stop FB execution
TRUE
Start one-time FB execution
uCommandID
WORD
ID of the command to be executed
→ Table: System commands (→ p. 122)
→ Table: AS-i master commands (→ p. 123)
uTarget
INT
Device component to which the
command is to be sent
0
system
1
AS-i master 1
2
AS-i master 2
pDataIn
POINTER TO
WORD
Buffer for data that is assigned to the
command as input parameters.
Commando parameter described in the
command request channel (word 3 to 120)
uSizeIn
WORD
Size of the buffer for the input
parameters (number of bytes)
pDataOut
POINTER TO
WORD
Buffer for data that is returned as
output parameters (results)
Return values described in the command
reply channel (data as of word 5)
uSizeOut
WORD
Size of the buffer for the output
parameters (number of bytes)
>
Table: System commands
17053
uCommandID
Description
0x0001
DS1 – System information
0x1101
Command 0x0101 – Quick set-up AS-i masters 1 + 2
0x1103
Command 0x0103 – Select user language
0x1104
Command 0x0104 – Change display settings
0x1105
Command 0x0105 – Set output control
0x1109
Command 0x0109 – Set date / time
0x110A
Command 0x010A – Configure the NTP server settings
0x110B
Command 0x010B – Read date / time / NTP settings
0x110C
Command 0x010C – Reboot system
0x110D
Command 0x010D – Read fieldbus info
0x1110
Command 0x0110 - Display target visualisation
Only execute system commands with the input parameter uTarget = 0!
Detailed information about the acyclic data sets and the command interface is given in the
supplement to the device manual of the AS-i Gateway AC14 (→ Overview: User documentation
for AS-i Gateway AC14 (→ p. 5)).
