ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Appendix Library ACnnnn_SYS_CMD.library
>
Table: AS-i master commands
17054
uCommandID
Description / corresponding command
0x0002
DS2 – Digital slave inputs and master flags
0x0003
DS3 – Analogue inputs of the slaves 1(A)...15(B)
0x0004
DS4 – Analogue inputs of the slaves 16(A)...31(B)
0x0005
DS5 – Digital slave outputs
0x0006
DS6 – Analogue outputs of the slaves 1(A)...15(B)
0x0007
DS7 – Analogue outputs of the slaves 16(A)...31(B)
0x0008
DS8 – Status flags of the analogue outputs of slaves 1...31
0x0009
DS9 – Slave lists LAS, LDS, LPF, LCE
0x000A
DS10 – Slave list LPS
0x000B
DS11 – Current configuration data (CDI)
0x000C
DS12 – Projected configuration data (PCD)
0x000D
DS13 – Image of the input parameters of the slaves (PI)
0x000E
DS14 – Image of the outputs parameters of the slaves (PP)
0x000F
DS15 – Slave error counter, configuration error counter, AS-i cycle counter
0x0011
DS17 – AS-i master: Error lists LCEMS, LCEAS, LDAE
0x1001
Command 0x0001 – Change AS-i slave parameters
0x1003
Command 0x0003 – Project current AS-i network
0x1004
Command 0x0004 – Change LPS
0x1005
Command 0x0005 – Change the operating mode of the AS-i master
0x1006
Command 0x0006 – Change AS-i slave address
0x1007
Command 0x0007 - Set auto address mode of the AS-i master
0x1009
Command 0x0009 – Change extended ID1 in the AS-i slave
0x100A
Command 0x000A - Change PCD
0x100D
Command 0x000D – AS-i master supply voltage, symmetry, earth fault
0x1015
Command 0x0015 – Read ID string of an AS-i profile (S-7.4)
0x101A
Command 0x001A – Read AS-i master info
0x101C
Command 0x001C – Deactivate slave reset when changing to the protected mode
0x1021
Command 0x0021 - Read diagnostics string of an AS-i slave (S-7.4)
0x1022
Command 0x0022 - Read parameter string of an AS-i slave (S-7.4)
0x1023
Command 0x0022 - Write parameter string of an AS-i slave (S-7.4)
0x1024
Command 0x0024 – CTT2 standard read
0x1025
Command 0x0025 – CTT2 standard write
0x1026
Command 0x0026 – CTT2 vendor specific read
0x1027
Command 0x0027 – CTT2 vendor specific selective write
0x1040
Command 0x0040 – CTT2 device group read
0x1041
Command 0x0041 – CTT2 device group write
0x1042
Command 0x0042 – CTT2 vendor specific selective read from buffer
0x1043
Command 0x0043 – CTT2 vendor specific selective write from buffer
