ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Appendix Library ACnnnn_Utils.library
>
ASI_ANALOG_OUT (STRUCT)
15995
The structure represents the process data of the analogue output slaves as well as the transmitted
flags.
Designation
Data type
Description
Possible values
 chan_1
INT
Analogue value channel 1:
S or A output slave
corresponds to the acyclic data records 6
and 7 (DS6, DS7)
→ DS6 – Analogue outputs of slaves 1(A)...15(B)
→ DS7 – Analogue outputs of slaves
16(A)...31(B)
 chan_2
INT
Analogue value channel 2:
S or A output slave
 chan_3
INT
Analogue value channel 3:
S or B output slave
 chan_4
INT
Analogue value channel 4:
S or B output slave
 flags
ASI_ANALOG_OUT_
FLAGS
Status flags
→-ASI_ANALOG_OUT_FLAGS (STRUCT)
(→ p. 120)
>
ASI_ANALOG_OUT_FLAGS (STRUCT)
15997
The structure contains the status flags of the analogue output slave.
Name
Data type
Description
Possible values
 na1
BOOL
--
corresponds to the acyclic data record 8
(DS8)
→ DS8 – Status flags of analogue output data of
the slaves 1...31
 na2
BOOL
--
 na3
BOOL
--
 na4
BOOL
--
 na5
BOOL
--
 na6
BOOL
--
 na7
BOOL
--
 na8
BOOL
--
 OVA
BOOL
Output valid, S/A slave
 na9
BOOL
--
 OVB
BOOL
Output valid, B slave
 n10
BOOL
--
 TOA
BOOL
Transfer Output, S/A slave
 na11
BOOL
--
 TOB
BOOL
Transfer Output, B slave
 na12
BOOL
--
