ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Programming Use functions of the ifm package
>
Read network settings
18532
To read the network settings cyclically and offer them in the application:
Name
Description
Reference
Get_ASi_Data
Read the following datasets for network management in
batches and cycles:
 List of activated slaves (LAS)
 List of detected slaves (LDS)
 List of projected slaves (LPS)
 List of peripheral faults (LPF)
 List of configuration errors (LCE)
 List of configuration errors, missing slaves (LCEMS)
 List of configuration errors - additional slaves
(LCEAS)
 List of double address errors (LDAE)
 Configuration data image (CDI)
 Permanent configuration data (PCD)
 Input parameters (PI)
 Output parameters (PP)
→ Get_ASi_Data (→ p. 104)
Alternatively, this data can be read separately with the following FB:
>
Read parameter images
17569
Name
Description
Reference
Get_InputParameter
Read parameters of the inputs of the slaves at the AS-i
master (PI)
→ Get_InputParameter (→ p. 83)
Get_OutputParameter
Read parameters of the outputs of the slaves on the
AS-i master (PP)
→ Get_OutputParameter (→ p. 85)
>
read slave lists
18530
Name
Description
Reference
Get_LPS
Read list of projected slaves (LPS)
→ Get_LPS (→ p. 67)
Get_LDS
Read list of detected slaves (LDS)
→ Get_LDS (→ p. 65)
Get_LAS
Read list of activated slaves (LAS)
→ Get_LAS (→ p. 63)
Get_LPF
Read list of peripheral faults (LPF)
→ Get_LPF (→ p. 77)
Get_LCE
Read list of configuration errors (LCE)
→ Get_LCE (→ p. 69)
Get_LCEMS
List of configuration errors - read missing slaves
(LCEMS)
→ Get_LCEMS (→ p. 73)
Get_LCEAS
Read of the configuration errors - read additional slave
(LCEAS)
→ Get_LCEAS (→ p. 71)
Get_LDAE
Read list of double address errors (LDAE)
→ Get_LDAE (→ p. 75)
