ifm Programming Manual AS-i Gateway AC14 (4.2.x) 12/2017
Appendix Library ACnnnn_Utils.library
>
Output parameters
16108
Parameter
Data type
Description
Possible values
dwLCEMS_SA_Slaves
DWORD
List of configured but missing S/A
slaves. Each bit represents an AS-i
address:
 Bit 0 (LSB) = address 0
...
Bit 31 (MSB) = address 31/31A
Per bit:
0
No configuration error -
missing slave
1
Slave is projected but not
available
sdwLCEMS_B_Slaves
DWORD
List of the configured but non-existing
B slaves. Each bit represents an AS-i
address:
 Bit 0 (LSB) = not used
 Bit 1 = address 1B
...
Bit 31 (MSB) = address 31B
Per bit:
0
No configuration error -
missing slave
1
Slave is projected but not
available
xReady
BOOL
Signal indicates if the execution of the
FB is terminated.
FALSE
FB is inactive or being
executed.
TRUE
FB execution is terminated.
xBusy
BOOL
Signal indicates if the FB is executed.
FALSE
FB is deactivated or FB
execution is terminated.
TRUE
FB execution is started but not
yet terminated.
xError
BOOL
Signal indicates if errors occurred
while the FB was executed.
FALSE
FB is disabled or presently
executed or FB was executed
without error.
TRUE
An error occurred when the FB
was executed.
wDiagnostic
WORD
Diagnostic information
→ List below (Diagnostic codes)
Diagnostic codes:
 0x0000
No specific error is set
 0x0F01
Unknown error
 0x0F02
Unknown/invalid target
 0x0F03
Unknown command ID
 0x0F04
Invalid parameters
 0x0F05
Timeout during processing
