1.2 Specifications
Camera head format:1080I/119.88 Y Pb Pr 4:2:2
-HDTV Signal output
1080I/119.88 Y Pb Pr 4:2:2 3G HD SDI
1080I/119.88 Y Pb Pr 4:2:2 DUAL LINK
1080I/59.94 Y Pb Pr 4:2:2
-SDTV Signal output
525I/59.94
Camera head format:1080I/50 Y Pb Pr 4:2:2
-HDTV Signal output
1080I/50 Y Pb Pr 4:2:2
-SDTV Signal output
625I/50
Camera head format:1080P/25sF Y Pb Pr 4:2:2
-HDTV Signal output
1080P/25sF segmented Frame Y Pb Pr 4:2:2
1080P/25 Y Pb Pr 4:2:2
-SDTV Signal output
625I/50 (1080p25sF to Down Convert)
Camera head format:720P/50 Y Pb Pr 4:2:2
-HDTV Signal output
720P/50 Y Pb Pr 4:2:2
-SDTV Signal output
625I/50
Camera head format:1080P/50 Y Pb Pr 4:2:2
-HDTV Signal output
1080P/50 Y Pb Pr 4:2:2 3G HD SDI
1080P/50 Y Pb Pr 4:2:2 DUAL LINK
1080I/50 Y Pb Pr 4:2:2
-SDTV Signal output
625I/50
Camera head format:1080I/50 G B R 4:4:4
-HDTV Signal output
1080I/50 G B R 4:4:4 3G HD SDI
1080I/50 G B R 4:4:4 DUAL LINK
1080I/50 Y Pb Pr 4:2:2
-SDTV Signal output
625I/50
Camera head format:1080P/25sF G B R 4:4:4
-HDTV Signal output
1080P/25sF segmented Frame G B R 4:4:4 3G HD SDI
1080P/25sF segmented Frame G B R 4:4:4 DUAL LINK
1080P/25sF segmented Frame Y Pb Pr 4:2:2
1080P/25 G B R 4:4:4 3G HD SDI
1080P/25 G B R 4:4:4 DUAL LINK
1080P/25 Y Pb Pr 4:2:2
-SDTV Signal output
625I/50 (1080p25sF to Down Convert)
Camera head format:1080I/100 Y Pb Pr 4:2:2
-HDTV Signal output
1080I/100 Y Pb Pr 4:2:2 3G HD SDI
1080I/100 Y Pb Pr 4:2:2 DUAL LINK
1080I/50 Y Pb Pr 4:2:2
-SDTV Signal output
625I/50
Analog Frequency
characteristic
SDTV Signal output
(Downconverted from
1080I)
Y signal
Less than 60 Hz Falling characteristic
60 Hz to 4.5 MHz ± 0.5dB within
4.5 MHz to 5 MHz ± 1.0dB within
5 MHz or more Falling characteristic
Audio output signal
(MIC1 / 2 OUT)
Less than 100 Hz Falling characteristic
100Hz to 10kHz ± 1.0dB within
10kHz or more Falling characteristic
