1.2 Specifications
Power Power-supply voltage AC100V/110V/117V/220V/240V ± 10%
Power consumption CCU-980 self operation Approx. 110 VA
BS-98 self operation Approx. 80 VA
Environmental
condition
Using Workstation
temperature range
Operating temperature CCU : 0
℃
to +45
℃
BS : 0
℃
to +40
℃
Storage temperature : -30
℃
to + 60
℃
Using Workstation
humidity range
It is non-condensing 30% to 90%
External dimensions CCU-980 W483 × H133 × D454 (Not including protrusions)
BS-98 W219 × H125 × D457 (Not including protrusions)
Mass CCU : About 28kg BS : About 9kg
Aplike estanda EMC standards FCC15 Subpart B Class A / EN55103-1, EN55103-2
Safety standard EN60950-1
Quality control ISO 9001 (JIS Z 9901)
Security Trade Control Thawed relevant goods
Using Workstation
conditions
Electrical environment Normal living area
(I except the strong electric field, and magnetic field strength)
Apply standard SMPTE 292M, SMPTE 425M, SMPTE 372M, SMPTE 259M
■
Input Signals
Item Rating
GENLOCK signal
(HDTV/SDTV supported)
HDTV : PS 1Vp-p 75Ω bridged connection
or
Tri-level sync 0.6Vp-p ± 6dB 75Ω bridged connection
SDTV : BBS 1Vp-p 75Ω bridged connection
or
BBS (w/10 FIELD ID) SMPTE 318M 75Ω bridged connection
Return signal
(RETURN VIDEO)
3G-SDI/HD-SDI 4 channels 75Ω single end input
SD-SDI selection
Q-TV signal (Prompter)
Analog VBS 2 channels 1Vp-p 75Ω single end input
HD Q-TV signal
(Prompter)
HD-SDI Y Pb Pr 4:2:2 1 channels 75Ω single end input
INTERCOM signal
(ENG / PROD) 2 lines
Select from 4-wire/Clearcom/RTS
4-wire 2 channels
0dBm 600 Ω
Clearcom 2 channels -15dBs 200 Ω
RTS 2 channels
0dBm 200 Ω
PGM (Program audio)
+4dBs or 0dBs 3 channels 600 Ω /10k Ω
TALLY signal
Red / Green / Yellow Selected from the make contact / power supply
