47
BS-98 1409 VER1 (U) (E)
4.6 External Connections
■
COMMUNICATION Connector
This is the connector that connects the control inputs from the external INTERCOM system, program voice, and external TALLY
system.
The hex jack screw for the Japanese domestic models is 2.6 mm, and the hex jack screw for oversea models are #4-40UNC as the
standard specifications.
InsertionSide
――Receptacle――
BSside :【metric】17LE-13250-27(D3AB)-FA
  【inch】 17LE-13250-27(D3AC)-FA
Cableside :DB-25PF-Norequivalent
PinNo. Name Function I/O ExternalInterface
ENGCHIntercomShield
ENGCHIntercominputtotheCCU/BSfromthesystem(H)
ENGCHIntercominputtotheCCU/BSfromthesystem(C)
ProgramAudioChannel-1input(H)
ENGCHIntercomoutputtothesystemfromtheCCU/BS(H)
ENGCHIntercomoutputtothesystemfromtheCCU/BS(C)
Ground
YellowTallyInput(+)
RedTallyInput(+)
RedTallyCommon
ProgramAudioChannel-1input(C)
ProgramAudioChannel-1Shield
PRODCHIntercomoutputtothesystemfromtheCCU/BS(C)
PRODCHIntercomShield
PRODCHIntercominputtotheCCU/BSfromthesystem(H)
PRODCHIntercominputtotheCCU/BSfromthesystem(C)
Ground
PRODCHIntercomoutputtothesystemfromtheCCU/BS(H)
ProgramAudioChannel-2Shield
ProgramAudioChannel-3input(H)
ProgramAudioChannel-3input(C)
GreenTallyInput(+)
GreenTallyCommon
ProgramAudioChannel-2input(H)
ProgramAudioChannel-2input(C)
ENG(S)
ENGS-B(H)
ENGS-B(C)
PGM-1(H)
ENGB-S(H)
ENGB-S(C)
GND
YTALLYIN
RTALLYIN
RTALLYCOMM
PGM-1(C)
PGM-1(S)
PRODB-S(C)
PROD(S)
PRODS-B(H)
PRODS-B(C)
GND
PRODB-S(H)
PGM-2(S)
PGM-3(H)
PGM-3(C)
GTALLYIN
GTALLYCOMM
PGM-2(H)
PGM-2(C)
IN
IN
IN
OUT
OUT
GND
IN
IN
IN
OUT
IN
IN
GND
OUT
IN
IN
IN
IN
IN
○
○
○
○
○
○
1
2
3
4
5
6
○
○
○
○
○
○
7
8
9
10
11
12
○
○
○
○
○
○
13
14
15
16
17
18
○
○
○
○
○
○
19
20
21
22
23
24
○
25
