5.1 Settings from the BS Menu
PM OUT-1 Format selection of PM output 1
PM-2/WFM Format selection of PM output 2 or WFM output
HD PM Select the format of the output 3G/HD-SDI PM
SD SCREEN MODE Select a screen mode of the SDTV output
SYNC OUT Select the format of the SYNC OUT output
HD-SYNC 2-3ID ADD ON/OFF Selection of whether to add 2-3 ID signal to the SYNC output
SD-10 FIELD ID SIG ON/OFF Selection of whether to add 10 FIELD ID signal to the ENC output
RET VIDEO FORMAT
Return to a main menu screen.
RET 1 ******* IN FS ON/OFF Selection of FS ON/OFF and Display of RETURN-1 detection signal format
RET 2 ******* IN/OUT FS ON/OFF Selection of FS ON/OFF and Display of RETURN-2 detection signal format
RET 3 ******* IN FS ON/OFF Selection of FS ON/OFF and Display of RETURN-3 detection signal format
RET 4 ******* IN/OUT FS ON/OFF Selection of FS ON/OFF and Display of RETURN-4 detection signal format
ACTIVE-THROUGH ON/OFF ON/OFF selection of RETURN active through mode
SD SCREEN MODE Select a screen mode of the SDTV signal input
PHASE CONTROL
Return to a main menu screen.
SYNC CONT Set the vertical phase of SDTV and HDTV for external synchronization
HD V PHASE Set the vertical phase of HDTV output signal for external synchronization
(Format name) SYS1/SYS2
The simultaneous output, it is possible to individually adjust the system of SYS2 with SYS1
HD TRUNK Adjust the vertical phase of HD TRUNK signal
HD MASTER H PHASE
Adjust the horizontal master phase of HDTV output signal for external synchronization
HD OUT-1 H PHASE Adjust the horizontal phase of OUT-1 output signal for external synchronization
HD OUT-2 H PHASE Adjust the horizontal phase of OUT-2 output signal for external synchronization
HD OUT-3 H PHASE
Adjust the horizontal phase of OUT-3 HDTV output signal for external synchronization
HD PM H PHASE Adjust the horizontal phase of PM OUT output signal for external synchronization
HD TRUNK H PHASE Adjust the horizontal phase of HD TRUNK output signal for external synchronization
SD V PHASE Adjust the vertical phase phase of SDTV output signal for external synchronization
SD MASTER H PHASE
Adjust the horizontal master phase of SDTV output signal for external synchronization
SD OUT-3 H PHASE
Adjust the horizontal phase of OUT-3 SDTV output signal for external synchronization
SD SC PHASE COARSE Coarse adjustment of the phase of the SDTV subcarrier
SD SC PHASE FINE Fine adjustment of the phase of the SDTV subcarrier
SD ENC H PHASE Adjust the horizontal phase of SDTV ENC output signal for external synchronization
SD PM H PHASE Adjust the horizontal phase of SDTV PM output signal for external synchronization
SYNC OUT H PHASE Adjust the horizontal phase of the external synchronization output (SYNC OUT)
SYNC OUT V PHASE Adjust the vertical phase of the external synchronization output (SYNC OUT)
