5.1 Settings from the BS Menu
PGM2 TERM Select the line termination 600/10K
of PGM2
PGM2 INPUT LEVEL Select the Input level -20dB/0dB/4dB of PGM2
PGM3 TERM Select the line termination 600/10K
of PGM3
PGM3 INPUT LEVEL Select the Input level -20dB/0dB/4dB of PGM3
PGM MIX FRONT INCOM The selection as to whether or not to mix the PGM to FRONT INCOM
PGM -> FR-INCOM LEVEL
The adjustment of the PGM mix level in FRONT INCOM
■
ENGINEER (2/2)
HDTV VIDEO PROCESS
Return to a main menu screen.
GAMUT CLIP Select ON/OFF of the GAMUT CLIP function
LEVEL Set the level of GAMUT CLIP
HDTV BARS TYPE Select the type of HDTV COLOR BARS
ARIB BARS TYPE Select a pattern of ARIB BARS
SMPTE BARS TYPE1 Select a pattern of SMPTE BARS #1
SMPTE BARS TYPE2 Select a pattern of SMPTE BARS #2
CHAR LEVEL HDTV output character level. Factory setting
CHAR BG LEVEL HDTV output character background level. Factory setting
SDTV VIDEO PROCESS
Return to a main menu screen.
HV SLIM DTL TYPE Set horizontal and vertical SLIM DTL type of the SDTV system.
V SLIM DTL FREQ Set the frequency or boost band for SDTV system
FINE DTL Setting of FINE DTL
COMB COMB FILTER setting. Factory setting
COMB GAIN COMB FILTER GAIN. Factory setting
H FILTER Set of SDTV output horizontal filter
V FILTER Set of SDTV output vertical filter
MOTION DETECT Set the motion detection of Down Converter
GAMUT CLIP Select ON/OFF of the GAMUT CLIP function
LEVEL Set the level of GAMUT CLIP
SDTV SETUP SEL Factory setting
SDTV BARS TYPE Select the type of SDTV COLOR BARS
CHAR LEVEL Set of SDTV output Character Level
CHAR BG LEVEL Set of SDTV output character background level
