ILX Lightwave LDC-3700 Series User Manual

Figures 2.11 A - D show the possible configurations of connecting laser diodes and photodiodes with the
LDC-3700 Series Laser Diode Controllers.
Figure 2.11A
Common Laser Cathode - Photodiode Cathode
3900 Modular Laser Diode Controller
OUTPUT
Earth Ground
Figure 2.14B
Common Laser Cathode - Photodiode Anode
