Main switch:
The switch is used to turn the machine on and off. The switch
has additional emergency stop function.
Figure 11: oxidation protection
Oxidation protection/reduce of oxidation:
After casting this part is used to close the die outlet, when the
starter bar is out and to protect the die against oxidation and
burn out.
down inside (no vacuum) up inside (for vacuum)
position with starter bar in:
Figure 12: secondary chiller
Secondary chiller: This part allows you the fast cooling of big
tube, wire or sheet sizes.
LED light: Enables you to supervise the casting process.
