Indutherm CC3000 - Page 27

System
description
TechDoku_CC1000_VCC1000_CC3000_VCC3000_GenPM_GB_86025010_86025110.doc
4–10
Figure 20: backside of casting unit
Backside of drawing unit
Above: water hoses
Below
Key-connector: 50421030 – 50421032
Figure 21: Quattro-option
Quattro option: Shown here with the Quattro op-
tion (instead of the normal drawing unit).
# 71225042 at (V) CC1000
# 71227042 at (V) CC3000
Advantage is a higher pulling force.
Figure 22: Bending unit option
Bending unit: For up to 5 wires (V) CC3000.
# 71225031 at (V) CC1000
# 71227031 at (V) CC3000.
