InFocus IN5122 User Manual

29
BASIC MENU
Item Description
LOW POWER
Using the ◄/► buttons turns the Low Power mode on and off.
See LOW POWER in the SETUP menu (

39).
CEILING
Using the ◄/► buttons switches the ceiling mode.
See CEILING in the SETUP menu (

39).
REAR
Using the ◄/► buttons switches the rear projection mode.
See REAR in the SETUP menu (

39).
RESET
Performing this resets all of the BASIC MENU items except for
RESET FILTER HOURS and LANGUAGE.
A conrmation dialog will display. Using the ► button selects OK
and performs the reset.
RESET FILTER
HOURS
The air lter usage time is shown in the menu.
Performing this resets the lter timer which counts air lter usage
time.
A conrmation dialog will display. Using the ► button selects OK
and performs the reset.
See RESET FILTER HOURS in the SERVICE menu (

52).
LANGUAGE
Using the ◄/► buttons changes the display language.
See LANGUAGE in the SCREEN menu (

43).
ADVANCED MENU
Press the ► or SELECT button to use the PICTURE, IMAGE,
INPUT, SETUP, AUDIO, SCREEN, OPTION, NETWORK, and
SECURITY menus.
EXIT Press the ◄ or SELECT button to close the OSD menu.

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
