73
Presentation tools
You can also control the images using the menu on the Thumbnail screen.
PC-LESS Presentation (continued)
Operating the menu on the Thumbnail screen
Item Features
Moves to an upper folder.
SORT Allows you to sort les and folders as per the following.
RETURN
Press the ► cursor button or SELECT to return to the Thumbnail
screen.
NAME UP Sorts in ascending order by le name.
NAME DOWN Sorts in descending order by le name.
DATE UP Sorts in ascending order by le date.
DATE DOWN Sorts in descending order.by le date.
▲/▼ Go to previous / next page.
SLIDESHOW Congures and starts the Slideshow (
76).
RETURN
Press the ► cursor button or SELECT to return to the Thumbnail
screen.
PLAY Press the ► cursor button or SELECT to start the Slideshow.
START Sets the beginning number of the Slideshow.
STOP Sets the end number of the Slideshow.
INTERVAL Sets the interval time of the Slideshow.
PLAY MODE Selects the Slideshow mode.
SOURCE Switches the input port.
MENU Displays the menu.
REMOVE USB
Be sure to use this feature before removing the USB storage
device from the projector. After that, the projector will not
recognize a USB storage device until you insert it again into the
USB TYPE A input port.

Other manuals for InFocus IN5122

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InFocus IN5122 and is the answer not in the manual?

InFocus IN5122 Specifications

General IconGeneral
Matrix size0.63 \
Number of colors16.78 million colors
Native aspect ratio4:3
Projection distance- m
Projection technology3LCD
Supported aspect ratios4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)2000:1
Screen size compatibility35.4 - 358 \
Projector native resolutionXGA (1024x768)
Vertical synchronization (max)120 kHz
Vertical synchronization (min)50 kHz
Horizontal synchronization (max)106 kHz
Horizontal synchronization (min)15 kHz
FocusManual
Throw ratio1.5 - 2.5:1
Zoom capabilityYes
Focal length range- mm
Vertical lens shift range-20 - 0 °
Horizontal lens shift range-20 - 20 %
Lamp typeUHP
Lamp power245 W
Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)5000 h
3D-
Full HDNo
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, PAL, SECAM
Supported graphics resolutions1600 x 1200 (UXGA)
RMS rated power16 W
Number of built-in speakers2
BNC input ports5
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity1
Ethernet LAN data rates10, 100 Mbit/s
Cables includedAC, RCA, VGA
Power consumption (standby)- W
Noise level32 dB
CertificationUL, c-UL, FCC, CE
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorBlack
Cable lock slot typeKensington
Operating altitude0 - 2286 m
Operating temperature (T-T)5 - 35 °C
Weight and Dimensions IconWeight and Dimensions
Depth318.5 mm
Width401 mm
Height111 mm
Weight4800 g
Package depth420 mm
Package width560 mm
Package height197 mm
Package weight8200 g
