InFocus IN5122 User Manual

92
Troubleshooting
Situations that can be easily mistaken as a projector defect (continued)
Phenomenon Situations not caused by a projector defect
Reference
page
No sound can
be heard.
The signal cables are not connected correctly.
Correctly connect the audio cables.
9 ~ 13
MUTE is on.
Restore sound by pressing MUTE or the VOLUME +/-
button on the remote control.
18
The volume is adjusted too low.
Adjust the volume to a higher level using the menu feature
or the remote control.
18, 41,
42
The AUDIO SOURCE>INTERNAL SPEAKERS setting is
not correct.
Correct the AUDIO SOURCE>INTERNAL SPEAKERS setting in
the AUDIO menu.
41
The selected HDMI NOISE CANCEL mode is not correct.
Check each mode and select the correct one for your
HDMI™ audio device.
42
No images are
displayed.
The lens cover is attached.
Remove the lens cover.
4, 17
The signal cables are not connected correctly.
Correctly connect the connection cables.
9 ~ 13
Brightness is adjusted too low.
Adjust BRIGHTNESS to a higher level using the menu feature.
30
The computer cannot detect the projector as a plug and play monitor.
Make sure that the computer can detect a plug and play
monitor using another plug and play monitor.
9
The BLANK screen is displayed.
Press BLANK button on the remote control.
25
Although an image input source is plugged into the USB
TYPE B port, USB TYPE B
is set to MOUSE.
Change USB TYPE B to USB DISPLAY in order to project
the image input to the USB TYPE B port. (You will not be
able to use the simple mouse and keyboard feature in this
case.) Otherwise select another port for image input.
50
The projector does not recognize the USB storage
device inserted into USB TYPE A port.
Use the REMOVE USB feature rst, then remove the USB
storage device, and re-insert it into the port.
Before removing the USB storage device, be sure to use
the REMOVE USB feature on the thumbnail screen, which
appears when the USB TYPE A port is selected as the input
source.
11, 73

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
