13
ENGLISH
Replacing the lamp
$ODPSKDVD¿QLWHSURGXFWOLIH8VLQJWKHODPSIRUORQJSHULRGVRIWLPHFRXOG
cause the pictures to appear darker or the color tone to be poor. Note that each
lamp has a different lifetime, and some may rupture or burn out soon after you
start using them. It is recommended that you keep a spare lamp on hand. To order
a new lamp, contact your dealer and tell them the lamp part number.
Part number <IN5132, IN5134, IN5134a, IN5135> : SP-LAMP-080
Part number <IN5142, IN5144, IN5144a, IN5145> : SP-LAMP-081
1.
Turn the projector off, and unplug the power cord.
Allow the projector to cool for at least 45 minutes.
2.
Obtain a new lamp. If the projector is ceiling
mounted, or if the lamp has broken, you can ask
the dealer to replace the lamp for you, if desired.
In case of replacement by yourself, follow the following
procedure.
3.
Loosen the lamp cover screw (marked by arrow) and
then slide the lamp cover down and remove the cover.
4.
Loosen the 3 lamp screws (marked by arrows),
and slowly pull the lamp out by the handles. Never
loosen any other screws.
5.
Insert the new lamp, and retighten the 3
ODPSVFUHZV¿UPO\WRORFNWKHPLQSODFH
6.
Align the lamp cover with the projector and slide
WKHODPSFRYHUEDFNLQSODFH7KHQ¿UPO\IDVWHQ
the lamp cover screw.
7.
Turn the projector on and reset the lamp time
using the LAMP TIME item in the OPTION menu.
(1) Press the
MENU
button to display the menu.
+LJKOLJKW$'9$1&('0(18LQWKHPHQXXVLQJWKHźŸ
EXWWRQVWKHQSUHVVWKHŹEXWWRQ
(3) Highlight OPTION in the left column of the menu using the
źŸEXWWRQVWKHQSUHVVWKHŹEXWWRQ
+LJKOLJKW/$037,0(XVLQJWKHźŸEXWWRQVWKHQSUHVV
WKHŹEXWWRQ$GLDORJZLOODSSHDU
(5)
Press the
Ź
button to select ³OK” on the dialog and reset the
lamp time
NOTE2QO\UHVHWWKHODPSWLPHDIWHUUHSODFLQJWKHODPSWRHQVXUHSURSHU
functioning of the lamp counter.
CAUTION
Ź'RQRWWRXFKWKHLQVLGHRIWKHSURMHFWRUZKLOHWKHODPSLV
taken out.
4, 5
6
Handles
Lamp cover
3
To Next Page
