44
PICTURE menu
PICTURE menu
From the PICTURE menu, you can perform the items
shown in the table below.
Select an item using the ▲/▼ cursor buttons, and
press the ► cursor button or the ENTER button to
perform this item. Then follow the instructions below.
Item Description
BRIGHTNESS
Using the
◄/►
buttons adjusts brightness.
Dark
ó
Light
CONTRAST
Using the
◄/►
buttons adjusts contrast.
Weak
ó
Strong
GAMMA
Using the ▲/▼ buttons switches the gamma mode.
To adjust CUSTOM
Selecting a CUSTOM mode and then pressing the ► button or
the
ENTER
button causes a dialog to appear that will aid you in
adjusting the mode. This function is useful
when you want to change the brightness
of particular tones.
Choose an item using the ◄/► buttons,
and adjust the level using the ▲/▼ buttons.
You can display a test pattern to check your
adjustments by pressing the
ENTER
button.
Each time you press the
ENTER
button, the
pattern changes as per below.
No pattern
ð
Gray scale of 9 steps
Ramp
Gray scale of 15 steps
Except for the darkest bar on the left, the eight equalizing bars
correspond to the test pattern's eight tone levels (9 steps of gray
scale). If you want to adjust the 2nd tone from the left end on the test
pattern, use the equalizing adjustment bar “1”. The darkest test pattern
on the left cannot be controlled with any of equalizing adjustment bars.
• Lines or other noise might appear on the
screen when this function is operated, but
this is not a malfunction.
(continued on next page)
1 DEFAULT
1 CUSTOM
2 DEFAULT
2 CUSTOM
3 DEFAULT
7 CUSTOM 3 CUSTOM
7 DEFAULT 4 DEFAULT
6 CUSTOM
6 DEFAULT
5 CUSTOM
5 DEFAULT
4 CUSTOM
To Next Page
