33
Operating
PERFECT FIT:
When PERFECT FIT is highlighted, pressing the
► or
ENTER
button displays the KEYSTONE_
PERFECT FIT dialog.
This projector is equipped with a test pattern for
PERFECT FIT. Select the test pattern icon
shown in the lower left of the dialog with the ◄/▼
buttons. When you press the
ENTER
or
INPUT
button, the test pattern appears or disappears.
1.
If it is necessary to initialize the current
adjustment, point at RESET in the dialog
with the
RESET
button, and press the
ENTER
or
INPUT
button.
2.
Select one of the corners to be adjusted with
the ▲/▼/◄► buttons and press the
ENTER
or
INPUT
button.
IN5132
,
IN5142
,
IN5134
,
IN5134a
,
IN5144,
and
IN5144a only:
the sides
can also be adjusted.
MANUAL:
When MANUAL is highlighted, pressing the ► or
ENTER
button displays the KEYSTONE_MANUAL
dialog.
1.
Select vertical or horizontal keystone ( / )
with the ▲/▼ buttons.
2.
Use the ◄/► buttons to adjust the keystone distortion.
Correcting the distortion (continued)
(continued on next page)
• When the zoom adjustment is set to the TELE (telephoto focus), this
function may be excessive. This function should be used when the zoom ad-
justment is set to the full WIDE (wide-angle focus) whenever possible.
• When the horizontal lens shift is not set to the center, this function may not
work well.
• Point at RETURN in the dialog with the ▲/▼ buttons and press ◄ or the
ENTER button to return to the KEYSTONE menu.
NOTE
IN5132, IN5142, IN5134,
IN5134a, IN5144, IN5144a
IN5135, IN5145
To Next Page
