LP500 Series Service Manual 115
Part Name Projector Part Number Notes
Rear bezel Both 505-0837-xx Also called I/O panel cover. Also requires rear
bezel label (020-1137-xx)
Rear bezel label Both 020-1137-xx Required for a new rear bezel.
Rubber foot Both 328-0029-xx
Safety switch assembly Both 526-0080-xx Includes thermal switch and interlock switch.
Safety switch cable Both 211-0162-xx Connects the interlock switch assembly with the
power supply.
Speaker Both 505-0960-xx Requires new speaker gasket.
Speaker bracket Both 340-0888-xx
Speaker gasket Both 329-0276-xx Required when replacing speaker.
Thermal switch clip Both 206-0032-xx Fastens the thermal switch to the lamp housing.
Top case Both 505-0835-xx
Zoom ring Both 505-0839-xx
