InFocus LP500 Service Guide

LP500 Series Service Manual 119
Fasteners and Torque Settings
Below is a list of the fasteners included in the fastener kit (802-0027-xx) for the LP500 and LP530
projectors. You'll also find the suggested torque settings for each fastener.
Fastener Application Torque
Jack nut 4-40 w/lock I/O EMI shield to controller ECA (2) 2 in.-lbs. (.226 Nm)
M1.8x8 Phillips Plastite Interlock switch to lamp housing (1) 4 in.-lbs. (.452 Nm)
M2.5x6 Black Torx
Plastite
Leveling foot (1) 4 in.-lbs. (.452 Nm)
M3x6 Torx
Ground clip to chassis (1), diode heat sink bracket to
chassis (1)
6 in.-lbs. (.68 Nm)
M3x6 Torx, Black
Plastite
Speaker to speaker bracket (2), Keypad to top case
(2), IR ECA to top case (1)
4 in.-lbs. (.452 Nm)
M3x8 Torx with
shoulder washer
Power supply (6) to chassis, optical engine to bottom
case (3), rear bezel to chassis (2), chassis to engine
(2), lamp connector to lamp housing (2), controller
ECA (8), speaker bracket to chassis (1), lamp housing
to engine (1)
Lamp connector: 4 in.-
lbs. (.452 Nm)
Others: 6 in.-lbs. (.68
Nm)
M3x8 Black Torx Front bezel (2) 4 in.-lbs. (.452 Nm)
M3x8 Torx Plastite
Chassis to bottom case (2), engine mount bracket to
bottom case (1), lamp blower (1), optical engine to
bottom case (3)
6 in.-lbs. (.452 Nm)
M3x8 Black Torx
Plastite
Front bezel vent (1) 4 in.-lbs. (.452 Nm)
M3x10 Torx Power supply fan to chassis (2) 6 in.-lbs. (.68 Nm)
M3x12 Torx Plastite Lamp fan (2) 6 in.-lbs. (.68 Nm)
M3x14 Philips Pan
Head
Front fan to optical engine (2) 6 in.-lbs. (.68 Nm)
M3x48 Black Torx Top case to bottom case (2) 4 in.-lbs. (.452 Nm)
