LP500 Series Service Manual 116
FRUs by numeric listing
Below is a numerically arranged list of FRUs used in the LP500 and LP530 projectors. You can also view
FRUs by alphabetic listing (see page 113).
Part Number Part Name Projector Notes
020-1102-xx Certification label LP530
020-1112-xx InFocus nameplate
label
Both
020-1136-xx Certification label LP500
020-1137-xx Rear bezel label Both
206-0032-xx Thermal switch clip Both Fastens the thermal switch to the lamp
housing.
211-0161-xx Controller/power
supply cable
Both
211-0162-xx Interlock switch
cable
Both Connects the interlock switch assembly
with the power supply.
321-0170-xx Elevator spring Both
328-0029-xx Rubber foot Both
329-0251-xx PSA square Both Required for new lamp blower
329-0268-xx Power supply
insulator
Both Fits between the power supply and
chassis.
329-0276-xx Speaker gasket Both Required when replacing speaker.
329-0299-xx Lamp blower
gasket
Both
329-0301-xx Gap pad, rear
diode
Both Adheres to the diode heat sink bracket
(330-0742-xx).
329-0302-xx Gap pad, front
diode
Both Adheres to the chassis.
329-0306-xx Lamp fan heat
shield
Both Required for new lamp fan.
329-0337-xx Lamp blower heat
shield
Both Required for new lamp blower.
330-0702-xx Chassis Both
330-0703-xx I/O EMI shield Both
330-0724-xx Ground clip Both Fastens to the chassis. Grounds to the
optical engine.
330-0742-xx Diode heat sink
bracket
Both Also requires rear gap pad (329-0301-xx).
Fits between the chassis and the bottom
of the power supply.
