LP500 Series Service Manual 117
Part Number Part Name Projector Notes
340-0822-xx Elevator lever Both
340-0824-xx Leveling foot shaft Both
340-0837-xx Engine mount
spacer
Both
340-0851-xx IR lens, rear Both Snaps into rear bezel.
340-0876-xx Light block louver Both Prevents light leakage in louver near
elevator button. Fits on the inside of the
bottom case.
340-0886-xx IR lens, top Both Snaps into top case.
340-0888-xx Speaker bracket Both
505-0835-xx Top case Both
505-0836-xx Bottom case Both Includes leveling foot, rubber foot,
elevator, light block louver and engine
mount spacer.
505-0837-xx Rear bezel Both Also called I/O panel cover. Also requires
rear bezel label (020-1137-xx)
505-0839-xx Zoom ring Both
505-0840-xx Focus ring Both
505-0841-xx Lens cap Both
505-0842-xx Lamp door Both
505-0858-xx Lamp housing Both Does not include the safety switch
assembly, lamp fan, or lamp blower.
505-0878-xx Elevator shaft Both
505-0919-xx Leveling foot Both
505-0959-xx Front bezel Both
505-0961-xx Front bezel vent Both
505-1180-xx Optical engine LP530
505-1181-xx Optical engine LP500
510-1520-xx IR receiver ECA Both
510-1530-xx Controller ECA Both
510-1532-xx Power supply Both
510-1579-xx Controller ECA Both
526-0078-xx Lamp blower Both Requires lamp blower gasket (329-0299-
xx), lamp blower heat shield (329-0337-
xx), and PSA square (329-0251-xx). Also
included with new optical engine.
To Next Page
