SKYZER TECHNOLOGIES PAGE 16 OF 116
NITRO INGENICO ICT250 AND IWL252 2015 PAYMARK SOFTWARE OPERATING GUIDE Version 1.0
2.2.3 The iPP310 PIN pad
The Ingenico IPP310 PIN pad consists of the following elements:
The PINpad Handset:
The interface cable that connects the IPP310 PIN pad to the iCT250 terminal:
The PIN shield for the IPP310 PIN pad:
Connects on the
terminal end in USB
Host connection
port
Connects on the
iPP310 Pinpad

Ingenico iCT250 Specifications

General

Memory	16 MB RAM, 128 MB Flash
Card Readers	Magnetic stripe, Smart card, Contactless
Operating System	Telium 2
Connectivity	Ethernet
Security	PCI PTS 3.x certified
Printer	Integrated thermal printer
Supported Cards	Visa, Mastercard, American Express, Discover
Display	128x64 pixel LCD, Backlit
Power Supply	External power adapter
