NITRO INGENICO ICT250 AND IWL252 2015 PAYMARK SOFTWARE OPERATING GUIDE Version 1.0
15.10 REPLACING PAPER ROLL
o Insert the paper roll in the compartment following the directions shown
on the figure below.
o Pull the paper up to the top of the terminal and hold it in this position.
o Maintain the paper and close the lid.
o Press the top of the lid in the centre as shown by arrow, until it clips into
position.
ADVISE: If you are inserting a new roll, tear off the first length (one complete
turn).
15.11 PAPER SIZE
The paper roll size is 58mm width and 40mm diameter max.
15.12 OPENING SIM CARD COMPARTMENT COVER
In order to access the GPRS SIM card slot, you must first remove the SIM card
compartment cover located at the back of your terminal.
o Press down firmly on the middle of the back cover and slide it as
indicated by the arrow as shown on the figure.

Ingenico iCT250 Specifications

General

Memory	16 MB RAM, 128 MB Flash
Card Readers	Magnetic stripe, Smart card, Contactless
Operating System	Telium 2
Connectivity	Ethernet
Security	PCI PTS 3.x certified
Printer	Integrated thermal printer
Supported Cards	Visa, Mastercard, American Express, Discover
Display	128x64 pixel LCD, Backlit
Power Supply	External power adapter
